When shopping for deck boards, you’ll often see sizes like 1×6, 5/4×6, and 2×6. These numbers refer to nominal lumber sizes, not the board’s finished dimensions. Thickness affects the deck’s appearance, how it feels underfoot, and how far the boards can span between joists.
What Is the Difference Between 1x, 5/4, and 2x Decking?
The main difference is thickness. Standard surfaced decking typically measures 3/4 inch thick for 1x boards, 1 inch for 5/4 boards, and 1 1/2 inches for 2x boards.
| Nominal board size | Typical finished thickness | Common application |
| 1×6 | 3/4 inch | Tropical hardwood decking |
| 5/4×6 | 1 inch | Standard residential decking |
| 2×6 | 1 1/2 inches | Thicker decking for a more substantial look |
These dimensions are typical for surfaced lumber. Composite, PVC, and specialty decking profiles may differ, so check the product specifications before ordering.
Nominal vs. Actual Deck Board Size
Lumber sizes can be confusing because nominal dimensions are larger than the finished board. A nominal 2×6, for example, typically measures 1 1/2 inches thick by 5 1/2 inches wide after surfacing.
The 5/4 designation refers to five quarters of an inch, or 1 1/4 inches, before surfacing. Standard finished 5/4 decking is typically 1 inch thick.
Knowing the actual dimensions helps when comparing products and planning details such as stair heights and transitions to adjoining surfaces.
1x Decking: A Slimmer, Often More Economical Option
Standard 1x decking is approximately 3/4 inch thick. It’s a common option for tropical hardwoods such as Ipe, Cumaru, Tigerwood, Garapa, and Teak.
Thinner boards are generally easier to handle. However, they may flex more between joists than thicker boards, so the wood species, framing layout, and product specifications all matter.
For many hardwood projects, standard 1x decking can be a practical choice when installed according to the applicable requirements.
5/4 Decking: A Versatile Choice
At approximately 1 inch thick, 5/4 decking offers a middle ground between standard 1x and 2x boards. It’s a popular size for residential decks and works well with a variety of decking materials, including tropical hardwoods.
If you want a familiar deck board profile without moving to thicker 2x material, 5/4 is a good place to start.
2x Decking: A Thicker, More Substantial Look
A nominal 2×6 deck board typically measures 1 1/2 inches thick by 5 1/2 inches wide. Its substantial appearance can suit rustic decks, porches, and projects where the boards are meant to stand out.
The trade-off is additional material and weight. Thicker boards can also affect finished elevations, stair dimensions, and transitions to other surfaces. For many residential decks, a thinner hardwood board may be sufficient, depending on the species, product, and framing design.
How Thickness Affects Joist Spacing
Deck boards span the joists beneath them, so their ability to resist bending matters when planning the frame. Thicker boards can often span farther, but allowable joist spacing
depends on the decking material, profile, installation direction, and manufacturer requirements.
Advantage Lumber’s published hardwood decking guidelines specify maximum joist spacing of 16 inches on center for standard 1×6 decking, 24 inches for 5/4×6, and 32 inches for 2×6. These recommendations apply to the relevant hardwood decking products and shouldn’t be assumed to apply to every type of decking.
Before building or modifying a deck frame, check the installation requirements for your exact product. Composite and PVC decking may have different spacing limits, and some installation patterns require closer joists.
Does Thicker Decking Last Longer?
Not necessarily. Thickness affects a board’s rigidity, but it doesn’t determine service life on its own.
Wood species, natural durability, moisture exposure, installation, and maintenance all play a role. A durable hardwood such as Ipe can provide decades of service when properly installed and cared for, even in a thinner decking profile.
Choose decking based on its overall performance and suitability for your project, rather than thickness alone.
Is There a Middle Ground Between 1x and 5/4 Decking?
Advantage Lumber’s 1×6 +Plus® decking measures approximately 21 mm, or 0.83 inch, thick. That makes it thicker than standard 1×6 decking but thinner than 5/4×6.
The added thickness is designed to provide greater stiffness than standard 1x decking. It’s worth considering if you want a little more substance without moving to full 5/4 decking. Available species include Ipe, Cumaru, Tigerwood, Teak, and Garapa.
Choosing the Right Deck Board Thickness
The right deck board thickness depends on your decking material, desired appearance, and framing requirements. Standard 1x, 5/4, and 2x boards each have a place in deck construction, so compare the actual dimensions and installation guidelines before making your choice.
